FNP X
Axel Kufus
The universal shelving system FNP combines minimal construction with maximum performance. FNP X / FNP X12 has been specifically adapted with its shallow depth to the dimensions of paperbacks.
Full of content and possibilities
Side holds rail. Rail holds base. Base holds rail. Rail holds side. Thanks to the simple and intelligent construction, the shelf can accommodate a maximum amount of content with a minimum material thickness and can be adapted to a number of room situations. Sometimes it follows the slope of the roof, sometimes it stands alone in the room, another time the FNP leaves a section for large screens or windows with a view. Corner solutions can also be implemented as well as door overhangs or a room in room.
Material
Corpus: FU (birch plywood), MDF or Bicolor
Rails: Aluminium untreated
Production
Produced in small craft companies in the Chiemgau region and surrounding area.
Still looking for just the right product? Plan your individual solution using our extended FNP X - configurator.
To configurator
Product Details
Description
FNP X
Design: Axel Kufus, 1997
A lot of content, little shelf
The universal shelving system FNP is synonymous with minimal construction and maximum performance. And has been for 30 years. The consistent and transparent shelf really looks good for its age. Which could be attributed to three decades of intelligent construction, regional production and sustainable use of materials combined with understatement. FNP is short for land-use plan (Flächennutzungsplan) in full length and breadth. Because in addition to the optimal use of both raw materials at 93 percent, it also adapts to every available space.
FNP shelf combines everything that is important to Moormann – consistency, transparency, posture and of course books.
In the meantime the shelf extends for kilometres and worldwide through flats, offices and libraries. What makes it the ideal roommate even after 30 years? FNP is not only clever, filigree, can handle loads, is stable, kind to resources, variable, easy to assemble and dismantle when moving and has lots of solution assistants such as boxes, lights or sliding doors, but has remained true to character. Which is down to the fact that the shelving system has only been cautiously elaborated and has been left as pure as it is. Even the shelf from the original year 1989 is still compatible with today’s system.
Material
Corpus
FU (birch plywood), MDF or Bicolor
Rails
Aluminium untreated
Material Properties and Care
FU Black (birch plywood)
Material properties:
Several birch veneers are cross-glued, creating a material with a high level of dimensional stability. Generally our birch plywood panels are surface-coated or oiled. They are produced in Finland. The slowly-growing trees in the Finnish climate create fine-grain wood of consistently high quality. The following properties can occur: knot inclusions on the edge and possibly different edge colors (image 1), inclusions, glossy stripes or matt areas on the surface (image 2).
Cleaning and care:
Light surface soiling on the untreated edges can be removed using fine-grain sandpaper. Coated surfaces can be cleaned using a soft cloth with lukewarm water and a small amount of colourless washing-up liquid. Please only wipe oiled surfaces with a slightly damp cloth and as necessary treat with colourless oil.
MDF Pure
Material properties:
To produce MDF materials, extremely fine, mainly bark-free wood is pressed homogenously in longitudinal and transverse direction to produce a dense wood material. Our MDF materials are produced in Germany and Austria. Characteristics of industrial production as well as slight color variations in different production batches are therefore visible. Due to signs of usage on the uncoated raw material, the furniture develops an individual character over its lifespan.
Cleaning and care:
MDF is a semi-finished material designed for coating. We use MDF for its characteristic aesthetic as an uncoated raw material. Contact or cleaning with liquids should therefore be avoided.
Light surface dirt on the untreated edges or surfaces can be removed using fine-grain sandpaper.
Dimensions
Dimensions in cm
Height: 103.2 / 223.0 / 259.6 / 299.0 (FU) / 332.8 (MDF, Bicolor)
Width: variable
Depth: 21.0
Individual sizes are possible.
Compartment dimensions
Height FNP X: 4.2 / 10.3 / 16.4 / 22.5 / 28.6 / 34.7
Height FNP X12: 4.6 / 10.7 / 16.8 / 22.9 / 29.0 / 35.1
Width FNP X: 23.2 / 48.0
Width FNP X12: 23.6 / 48.4
Material thickness
FU (birch plywood): 1.2
MDF, Bicolor: 1.6
Technical Details / Notes
General Information
Maximum load shelf boards width 23.2 / 23.6 cm: 25 kg / width 48.0 / 48.4 cm: 15 kg
FNP X/FNP X12 can be extended subsequently in width and add-ons.
2 brackets, screws and wall plug for wall mounting and balancing wedges for uneven floors are included in the delivery.
FNP X can be combined with FNP.
Available in
MDF pure
MDF black waxed
MDF brown waxed
MDF red waxed
MDF white (approx. RAL 9003)
MDF black (approx. RAL 9005)
Bicolor white (approx. RAL 9003)
Bicolor black (approx. RAL 9005)
FU white (approx. RAL 9003)
FU black (not specified, wood structure slightly visible)
Shipping and Assembly
The individual units are shipped in flat pack form.
For larger configurations we recommend assembly by a professional assembly team.
Wall or ceiling mounting is necessary. A bracket for wall mounting is included in the delivery.
FNP X Examples
Gallery
Accessories
Library (4)
Organisation (1)
Assembly (3)
Electronic (2)
Construction (2)
Tray (1)
